Schneider XB4BA42 Harmony
Schneider XB4BA42 | Harmony Push Button
1. Overview
The Schneider XB4BA42 Harmony is a high-quality, industrial-grade push button designed for control and automation applications. It features a flush red actuator, a 22mm metal body, and a spring return mechanism for momentary operation. With 1 Normally Closed (NC) contact, it is ideal for emergency stop or circuit control applications.
2. Key Features
- Durable Metal Construction: Ensures high resistance to mechanical and environmental stress.
- Flush Red Actuator: Designed for easy identification and quick operation.
- 22mm Mounting Diameter: Standard size for industrial control panels.
- Spring Return Mechanism: Returns to the original position after release.
- 1 NC (Normally Closed) Contact: Suitable for safety circuits and machine stop functions.
- Unmarked Actuator: Can be customized with labels if needed.
3. Technical Specifications
- Product Series: Harmony XB4
- Material: Metal
- Mounting Diameter: Ø22mm
- Button Type: Flush, unmarked
- Actuation: Spring return (momentary action)
- Contact Type: 1 NC (Normally Closed)
- Color: Red
- Electrical Durability: Designed for high-frequency use
- Compliance: IEC & UL standards for industrial applications
4. Benefits
- Reliable Control Functionality: Ensures precise momentary switching.
- Long-Term Durability: Built for harsh industrial environments.
- Quick and Easy Installation: Standard 22mm mounting hole.
- Versatile Use: Suitable for stop functions, alarms, and control circuits.
5. Applications
- Industrial control panels
- Machinery stop buttons
- Automation systems
- Emergency control circuits
6. Conclusion
The Schneider XB4BA42 Harmony Push Button is a robust and reliable choice for industrial control applications. Its durable metal construction, spring return mechanism, and 1 NC contact make it ideal for safety and automation circuits.
