Description

Schneider LC1D80E7| TeSys D contactor – 3P(3 NO) – AC-3 – <= 440 V 80 A – 48 V AC 50/60 Hz coil



Schneider LC1D80E7 Contactor: Comprehensive Overview

The Schneider LC1D80E7 is a high-capacity contactor designed for industrial applications that require reliable motor control and load management. Known for its robust design and energy efficiency, it is a trusted solution for heavy-duty electrical systems.

Technical Specifications

• Model Number: LC1D80E7
• Rated Current (AC-3): 80 A
• Voltage Rating:
  • Coil Voltage: 48V AC
  • Operating Voltage: Up to 690V AC
• Power Rating: Supports motors up to 37 kW at 400V
• Auxiliary Contacts: 1 NO (Normally Open) + 1 NC (Normally Closed)
• Frequency Range: 25 to 400 Hz
• Mounting Type: Suitable for DIN rail or panel mounting
• Dimensions: Compact and lightweight for easy installation.

Key Features

1. Durable and Reliable:
   The LC1D80E7 is built to handle demanding environments, ensuring long-term reliability.
2. Energy-Efficient Coil:
   The low-power consumption coil optimizes operational costs while delivering consistent performance.
3. Space-Saving Design:
   Its compact size ensures seamless integration into control panels with limited space.
4. Versatile Compatibility:
   Compatible with a range of auxiliary devices from Schneider Electric for expanded functionality.
5. Enhanced Safety Measures:
   Advanced insulation and adherence to international standards guarantee secure operation.

Applications

The Schneider LC1D80E7 is versatile and supports various applications, including:

• Motor Control: Manages motor starting, stopping, and reversing in industrial setups.
• Industrial Automation: Provides precise load management in automated systems.
• HVAC Systems: Ensures reliable operation in heating, ventilation, and air conditioning systems.
• Power Distribution: Integral to load switching and protection in factories and commercial buildings.

Installation and Maintenance

• Installation Tips:
  • Mount securely on a DIN rail or panel, ensuring proper alignment.
  • Verify coil and load compatibility before wiring.
• Maintenance Recommendations:
  • Inspect periodically for signs of wear or dust accumulation.
  • Clean and test the auxiliary contacts to maintain optimal performance.
