Schneider E3SUPS40KHB2 On-Line UPS, 40kVA/40kW, 3 Ph, 3S, 400V 3:3, UPS, 4 internal 7Ah modular battery strings, Tower

Schneider E3SUPS40KHB2 On-Line UPS

40kVA/40kW, 3 Ph, 3S, 400V 3:3, UPS, 4 internal 7Ah modular battery strings, Tower

High-Performance On-Line UPS for Critical Power Protection:

Schneider E3SUPS40KHB2 is a robust and efficient 40kVA/40kW 3-phase on-line Uninterruptible Power Supply (UPS) designed to deliver reliable power protection for small to medium data centers and electrical rooms.

Built with advanced double conversion technology, this UPS ensures continuous, clean power delivery to critical equipment.

With support for extended runtime options and redundancy configurations, it’s a scalable solution for growing power needs.

Its compatibility with various voltage inputs (380V, 400V, 415V) that is makes it flexible for different electrical infrastructures.

Effortless Installation, Operation, and Maintenance:

Designed with user-friendliness in mind, the Easy UPS 3S is exceptionally easy to install and operate.

Besides intuitive startup procedures and an included installation guide, deployment is streamlined even in time-sensitive environments.

The unit’s modular battery strings, tool-free access, and front-facing components make routine maintenance fast and safe.

This helps reduce downtime and total cost of ownership, that is allowing for a smoother user experience over the UPS’s lifecycle.

Reliable Internal Battery System with Schneider E3SUPS40KHB2 On-Line UPS:

Equipped with four internal 7Ah modular VRLA battery strings, the E3SUPS40KHB2 ensures immediate backup during power interruptions.

Each battery string is rated at 240V, providing sufficient runtime for short outages.

For longer backup requirements, the UPS supports external battery packs,

that is enabling scalable runtime depending on the application.

Besides no free battery slots internally, external expansion is the go-to solution for runtime extension without compromising the compact tower form factor.

Advanced Power Efficiency and Clean Output:

The Uninterruptible Power Supply (UPS) delivers a power factor of 1.0 (40kW = 40kVA) and features an impressive input power factor of 0.99, significantly reducing energy losses.

It also maintains input harmonic distortion under 3%, which helps preserve power quality and ensures compliance with electrical standards.

The output voltage regulation is tightly controlled within ±1.5%, and total harmonic distortion is kept under 3% for linear loads,

whereas ensuring that sensitive electronics and servers receive stable and clean power at all times.

Built for Harsh Environments and Industrial Applications:

With its dust filter and conformal-coated circuit boards, the E3SUPS40KHB2 UPS 3-Phase is engineered to withstand harsh environments.

It operates efficiently in ambient temperatures from 0 to 40°C, with a relative humidity tolerance of up to 95% non-condensing.

That is durability makes it suitable for challenging industrial settings, remote locations, or high-dust environments.

The UPS is also CE, EAC, and RCM certified, assuring users of compliance with international safety and performance standards.

Compact Footprint and Intelligent Design with Schneider E3SUPS40KHB2 On-Line UPS:

Despite its high capacity, the E3SUPS40KHB2 UPS maintains a compact design with a footprint of just 50 cm (W) x 96.9 cm (D) x 140 cm (H) and a net weight of 590 kg.

The white RAL 9003 finish offers a clean, modern look suitable for data center environments.

The built-in USB interface supports convenient configuration and monitoring,

while the unit’s IP20 protection rating helps safeguard internal components from external contact and debris.

Peace of Mind with Comprehensive Warranty:

The E3SUPS40KHB2 comes with a 2-year on-site repair or replacement warranty,

that is including factory-authorized start-up support.

This comprehensive coverage ensures long-term reliability and peace of mind for your investment.

With Schneider Electric’s global support network, spare parts, and service availability, you can count on continuous power protection and expert support when it matters most.
