Schneider E3SUPS20KHB1 On-Line UPS, 20kVA/20kW, 3 Ph, 3S, 400V 3:3 UPS, 2 internal 7Ah modular battery strings, expandable to 3, Tower

Description

Schneider E3SUPS20KHB1 On-Line UPS

20kVA/20kW, 3 Ph, 3S, 400V 3:3 UPS, 2 internal 7Ah modular battery strings, expandable to 3, Tower

High-Performance 20kVA On-Line UPS for Critical Power Needs:

Schneider E3SUPS20KHB1 Easy UPS 3S is a high-efficiency, double-conversion on-line uninterruptible power supply designed for maximum business continuity in demanding environments.

Delivering 20kVA / 20kW of reliable power output, this 3-phase UPS (400V) ensures stable energy delivery,

that is ideal for small to medium data centers, commercial buildings, and electrical rooms.

Its advanced electrical design and rugged build provide top-tier performance with a strong focus on durability and ease of use.

Schneider E3SUPS20KHB1

Easy Installation, Operation, and Maintenance with Schneider E3SUPS20KHB1 On-Line UPS:

Engineered for simplicity, the Easy UPS 3S also offers plug-and-play installation, minimal setup time, and intuitive controls.

Whether you’re integrating it into a new system or replacing an older UPS, users benefit from reduced commissioning time and streamlined maintenance.

Besides user-friendly diagnostics, a dust filter, and conformal-coated boards, this UPS is also built to perform well in harsh environments.

Flexible Runtime Options with Modular Battery System:

The E3SUPS20KHB1 also includes 2 internal 7Ah VRLA modular battery strings, expandable to 3 strings,

that is giving users the flexibility to extend runtime as needed.

Operating at a 240V battery voltage, the modular system allows for easy battery upgrades or replacements, improving long-term serviceability.

This UPS can also be scaled up to support extended runtime options with additional battery packs.

Schneider E3SUPS20KHB1 On-Line UPS

Exceptional Power Quality and Efficiency of Schneider E3SUPS20KHB1 On-Line UPS:

This Schneider UPS 3 Phase offers true double-conversion technology, that is ensuring consistent and clean power delivery with <3% total harmonic distortion and +/- 1.5% voltage tolerance.

With an input power factor of 0.99 and <3% input harmonic distortion, it optimizes energy usage while minimizing electrical noise and heat.

Operating at up to 96% efficiency, it reduces operational costs and carbon footprint, making it ideal for energy-conscious facilities.

Scalability and Redundancy for Growing Operations:

Designed for evolving business needs, the Easy UPS 3 Phase supports up to 4 parallel units for either capacity expansion or redundancy, ensuring uninterrupted power supply in mission-critical applications.

This scalability provides peace of mind for businesses planning future growth without having to reinvest in entirely new UPS systems.

Schneider UPS

Robust Environmental and Safety Standards:

Besides an operational temperature range of 0–40°C, humidity tolerance up to 95% non-condensing,

and an IP20-rated enclosure, the E3SUPS20KHB1 is ready for a wide range of environments.

Certified to CE, EAC, and RCM standards, the Schneider UPS 3 Phase meets international safety and quality benchmarks.

The built-in dust filter further protects internal components, extending lifespan and reliability.

Compact, Powerful, and Built to Last of Schneider E3SUPS20KHB1 On-Line UPS:

Despite its power, the Schneider uninterruptible power supply boasts a compact tower form factor, measuring 140 cm (H) x 38 cm (W) x 92.8 cm (D) and weighing 446 kg (excluding batteries).

Its sleek white (RAL 9003) finish complements modern server rooms, while its quiet operation at 60 dBA makes it suitable for noise-sensitive environments.

Warranty and Support:

The Schneider Easy UPS 3S comes with a 2-year on-site repair or replace warranty, including factory-authorized start-up services.

Backed by Schneider Electric’s global support network, customers can be confident in reliable service and technical assistance whenever needed.
