Schneider E3SUPS15KHB On-Line UPS, 15kVA/15kW, 3 Ph, 3S, 400 V 3:3 UPS for internal batteries, Tower

Schneider E3SUPS15KHB On-Line UPS

15kVA/15kW, 3 Ph, 3S, 400 V 3:3 UPS for internal batteries, Tower

Schneider Electric E3SUPS15KHB 15kVA On-line UPS:

Schneider E3SUPS15KHB On-Line UPS is a high-efficiency 3-phase Uninterruptible Power Supply designed to deliver 15kVA/15kW of reliable power for business-critical applications.

As part of the Easy UPS 3S range, this double-conversion online UPS is engineered to ensure maximum uptime and continuity for small to medium-sized data centers, electrical rooms, and commercial environments.

Its robust build, competitive technical specifications, and advanced features make it an ideal choice for organizations looking for a simple yet powerful power protection solution.

High Efficiency and Double Conversion Technology:

The E3SUPS15KHB features true double-conversion online topology,

that is offering maximum protection against all types of power disturbances.

It ensures stable output voltage and frequency, regardless of input conditions.

The UPS also provides high operating efficiency, even at partial loads, reducing energy consumption and lowering operating costs.

Besides a load power factor of 0.9 and input power factor of 0.99, it minimizes energy losses and improves performance in demanding applications.

Flexible Installation and Scalable Configuration:

Designed with ease of use in mind, this tower-format UPS is exceptionally simple to install, operate, maintain, and service.

Its modular architecture supports up to four parallel units for either capacity expansion or redundancy, giving businesses flexibility as their power demands grow.

The UPS supports internal batteries and allows runtime customization based on specific needs.

Battery slots are provided but not pre-filled, allowing users to select and install VRLA batteries as needed.

Advanced Input and Output Performance:

This 3-phase UPS operates at a primary input voltage of 400V (also compatible with 380V and 415V) and delivers the same for output.

The system can handle a wide input voltage range (304–477V) and operates within 45–65 Hz, syncing with the mains.

It provides harmonic distortion of less than 3%, ensuring clean, high-quality power to connected equipment.

The output voltage tolerance of ±1.5% guarantees stability even under variable load conditions.

Rugged Design for Harsh Environments:

Built to withstand demanding environments, the Schneider E3SUPS15KHB includes features such as:

conformance-coated circuit boards and a dust filter, extending operational life and reliability in dusty or humid areas.

It operates efficiently in ambient temperatures from 0 to 40°C and humidity levels up to 95% non-condensing.

It also maintains full performance up to 1,000 meters of altitude, supporting installations across diverse locations.

Compact Dimensions and Quiet Operation:

Besides a compact footprint of 140 cm (H) x 38 cm (W) x 92.8 cm (D) and a net weight of 112 kg,

this UPS power supply can fit into tight spaces without compromising performance.

The acoustic noise level is kept at a modest 60 dBA, that is allowing it to be installed in proximity to working personnel without causing disruptions.

It includes a USB interface for easy communication and integration with monitoring systems.

Certified Quality and Reliable Warranty:

The E3SUPS15KHB meets international standards with CE, EAC, and RCM certifications.

It also comes with a 2-year warranty that includes on-site repair or replacement and factory-authorized start-up services.

Besides its robust protection, scalable architecture, and easy maintenance,

the Schneider Electric Easy UPS 3S 15kVA is a trusted choice for businesses seeking dependable power continuity.
