Schneider E3MUPS120KHS On-Line UPS, 120kVA/ 120kW, 3 Ph, 3M, 400V, 3:3 UPS for external batteries, Start-up 5×8, Tower

Schneider E3MUPS120KHS On-Line UPS

120kVA/ 120kW, 3 Ph, 3M, 400V, 3:3 UPS for external batteries, Start-up 5×8, Tower

Reliable High-Capacity UPS for Critical Applications:

Schneider Electric Easy UPS 3M E3MUPS120KHS 3 phase is a robust, double-conversion on-line uninterruptible power supply (UPS) system designed to deliver reliable power protection for business-critical applications.

Besides a power rating of 120 kVA / 120 kW, this 3-phase tower UPS ensures continuous power for medium-sized data centers, commercial buildings, and industrial setups.

Its scalable architecture supports parallel operation with up to six units for capacity expansion or redundancy,

whereas offering a high degree of flexibility and resilience.

Schneider E3MUPS120KHS

Flexible Battery Options for Custom Backup Solutions:

This UPS model is designed for external battery systems, that is enabling organizations to customize their runtime solutions to suit specific operational needs.

It is also compatible with Galaxy lithium-ion battery cabinets,

providing advanced energy storage options with longer life cycles, reduced maintenance,

and better performance in temperature-sensitive environments.

This level of flexibility makes the E3MUPS120KHS ideal for businesses seeking tailored backup power configurations.

High Efficiency and Power Quality with Schneider E3MUPS120KHS On-Line UPS:

The Easy UPS 3M series delivers outstanding electrical performance, with an input power factor of 0.99 and total harmonic distortion (THDi) of less than 3% at full load.

These features minimize energy losses and improve power quality.

Besides its double-conversion online topology ensures stable and clean power delivery,

that is protecting sensitive equipment from power disturbances.

The system supports a wide input voltage range (342–477 V) and frequency range (40–70 Hz), that is making it highly adaptable to varying power conditions.

Compact and User-Friendly Design:

Despite its powerful capabilities, the E3MUPS120KHS features a compact footprint with dimensions of 130 cm (H) x 50 cm (W) x 85 cm (D), and a net weight of 193 kg.

It also is easy to install, connect, and maintain.

The unit includes a touchscreen LCD control panel, that is providing intuitive access to UPS status and settings.

Pre-installed dust filters and built-in start-up service (5×8) further streamline installation and commissioning.

EcoStruxure™-Ready for Smart Monitoring:

Fully EcoStruxure™ IT-enabled, this UPS supports advanced remote monitoring and management via Schneider Electric’s cloud-based platform.

Businesses can monitor their power infrastructure in real time, receive alerts, and proactively manage risks with data-driven insights.

This feature enhances uptime and operational efficiency by enabling predictive maintenance and remote diagnostics.

Environmental and Safety Ratings of Schneider E3MUPS120KHS On-Line UPS:

The Schneider Easy UPS 3M operates reliably in ambient temperatures from 0°C to 40°C, with a relative humidity tolerance of up to 95% (non-condensing).

It has an IP20 protection rating, upgradeable to IP30 with an optional kit,

that is ensuring safe operation in controlled environments.

The acoustic noise level is measured at 72 dBA, and the system dissipates 20,473 BTU/h of heat during operation, highlighting its thermal management efficiency.

Peace of Mind with Comprehensive Warranty:

This UPS (uninterruptible power supply) also comes with a 2-year on-site repair or replace warranty,

supported by Schneider Electric’s factory-authorized start-up service, that is ensuring optimal performance from day one.

Included in the package are a dust filter, installation guide, and all necessary documentation for smooth deployment.

Schneider E3MUPS120KHS On-Line UPS is the Ideal UPS for Reliable Business Continuity:

The Schneider Electric Easy UPS 3M E3MUPS120KHS is a powerful, scalable, and intelligent UPS system tailored for organizations that demand continuous uptime.

Besides its superior design, flexible battery options, advanced monitoring features,

and energy efficiency make it the ideal solution for protecting mission-critical infrastructure.
