Schneider E3SUPS20KHB On-Line UPS, 20kVA/20kW, 3 Ph, 3S, 400V 3:3 UPS for internal batteries, Tower

Schneider E3SUPS20KHB On-Line UPS

20kVA/20kW, 3 Ph, 3S, 400V 3:3 UPS for internal batteries, Tower

Powerful and Reliable 20kVA Online UPS for Critical Infrastructure:

Schneider Easy UPS E3SUPS20KHB 3 phase is a high-performance, double-conversion on-line UPS system designed to provide uninterruptible power supply to protect critical loads.

Besides a robust 20 kVA / 20 kW power rating and three-phase input/output (400V), this unit is built to support small to medium-sized businesses, data centers, and IT environments.

Its advanced features and industrial-grade design ensure maximum uptime and peace of mind during power disturbances.

Effortless Installation and Configuration:

One of the most notable advantages of this UPS is its simplified installation process.

The Easy UPS 3S series is engineered for fast deployment, with an intuitive interface, pre-installed dust filters,

and conformance-coated circuit boards that allow operation in harsh environments.

Schneider Electric has optimized the layout to reduce setup time and ensure that operators can bring the system online quickly with minimal technical expertise.

Modular Scalability for Capacity and Redundancy with Schneider E3SUPS20KHB On-Line UPS:

Flexibility is at the core of the E3SUPS20KHB design.

Users can parallel up to four UPS units to scale power capacity or to add redundancy.

That is makes it ideal for growing businesses that need a scalable power backup solution.

Whether you’re expanding your infrastructure or increasing availability, this UPS adapts to your needs with ease.

High Efficiency and Low Total Cost of Ownership:

Designed with energy efficiency in mind, the UPS delivers over 96% efficiency in double-conversion mode,

significantly reducing electricity costs and environmental impact.

At full load, it maintains a power factor of 0.99 and keeps input harmonic distortion under 3%.

This ensures efficient power utilization while minimizing stress on upstream electrical components, contributing to long-term savings.

Customizable Battery Runtime and VRLA Compatibility:

While the UPS 3 phase is built for internal battery installation, it is shipped without batteries,

that is giving users the flexibility to customize runtime according to their requirements.

Compatible with VRLA batteries and supporting 240V battery voltage, the system features three battery slots, offering extended runtime options.

Battery runtime details are available in the official runtime charts provided by Schneider.

Advanced Electrical and Environmental Protection of Schneider E3SUPS20KHB On-Line UPS:

The unit supports 304–477V input voltage range, operates within 45–65 Hz frequency,

and delivers stable output voltage with less than 3% harmonic distortion, that is making it ideal for sensitive equipment.

With an operating temperature range of 0–40°C, and a relative humidity tolerance of up to 95%, this UPS thrives in demanding environments.

The IP20-rated enclosure provides protection against dust and other non-corrosive elements.

Compact Design for Space Efficiency:

Despite its power, the uninterruptible power supply also features a tower form factor with a compact footprint, standing 140 cm high, 38 cm wide, and 92.8 cm deep.

Weighing only 122 kg, it is an excellent fit for data centers or electrical rooms where space optimization is critical.

Its elegant white RAL 9003 finish complements modern technical environments.

Reliable Warranty and Support:

Backed by a 2-year on-site repair or replacement warranty, the E3SUPS20KHB includes factory-authorized startup services for added assurance.

This ensures you get immediate support and extended product life, reinforcing Schneider Electric’s commitment to quality and reliability.
