Schneider E3SUPS15KHB1 On-Line UPS, 15kVA/15kW, 3 Ph, 3S, 400V 3:3 UPS, 1 internal 7Ah modular battery strings, expandable to 3, Tower

Schneider E3SUPS15KHB1 On-Line UPS

15kVA/15kW, 3 Ph, 3S, 400V 3:3 UPS, 1 internal 7Ah modular battery strings, expandable to 3, Tower

Schneider E3SUPS15KHB1 On-Line UPS is a high-performance uninterruptible power supply (UPS) designed to provide reliable power protection for critical systems.

Besides a capacity of 15 kVA/15 kW, this three-phase UPS operates at 400V and includes one internal 7Ah modular battery string, expandable to three for extended runtime.

Built for small and medium data centers, electrical rooms, and industrial applications, this UPS ensures business continuity with advanced features and a robust electrical design.

Schneider E3SUPS15KHB1

Easy Installation and Maintenance:

The Easy UPS 3S series is designed with simplicity in mind.

It is easy to install, operate, maintain, and service, that is making it a hassle-free power backup solution.

The unit comes with an installation guide and a dust filter,

whereas ensuring smooth setup and long-term performance in various environments.

Its user-friendly interface allows for quick configuration and monitoring, reducing downtime and maintenance efforts.

High Efficiency and Performance of Schneider E3SUPS15KHB1 On-Line UPS:

The Schneider E3SUPS15KHB1 offers high efficiency with its double-conversion online technology,

that is providing clean and stable power to connected devices.

With an input power factor of 0.99 and low harmonic distortion of less than 3%, it delivers optimal performance with minimal energy loss.

The UPS operates with a load power factor ranging from 0.9 leading to 0.9 lagging, ensuring compatibility with a wide range of equipment.

Schneider UPS

Flexible Power Input and Output:

This uninterruptible power supply (UPS) supports multiple input and output voltage options,

that is including 380V, 400V, and 415V, allowing adaptability to different power systems.

It can handle a maximum input current of 28A and maintains output voltage stability with a tolerance of +/- 1.5%.

The unit synchronizes output frequency with mains power at 50Hz or 60Hz,

whereas ensuring seamless integration into various power infrastructures.

Expandable Battery Backup for Extended Runtime:

Equipped with one internal 7Ah modular battery string, the Schneider E3SUPS15KHB1 can be expanded to accommodate up to three battery strings.

This flexibility allows businesses to extend runtime based on operational needs, that is ensuring uninterrupted power supply during outages.

The UPS uses VRLA (Valve-Regulated Lead-Acid) batteries with a battery voltage of 240V, that is providing reliable energy storage and distribution.

E3SUPS15KHB1 UPS device

Durable Design for Harsh Environments with Schneider E3SUPS15KHB1 On-Line UPS:

Engineered for durability, this UPS features conformance-coated boards and a dust filter, making it suitable for harsh environments.

It has an IP20 protection rating, shielding it from solid objects and dust.

The UPS can operate in ambient temperatures ranging from 0°C to 40°C and withstand relative humidity levels up to 95% (non-condensing), ensuring stable performance in diverse conditions.

Compact and Space-Saving Structure:

With a compact tower design, the Schneider E3SUPS15KHB1 Three-Phase UPS maximizes space efficiency without compromising performance.

Measuring 140 cm in height, 38 cm in width, and 92.8 cm in depth, this UPS is designed to fit seamlessly into data centers and electrical rooms.

Despite its powerful capabilities, the unit maintains a manageable weight of 436 kg, that is making transportation and installation easier.

E3SUPS15KHB1 UPS

Safety and Compliance Certifications:

This Three-Phase UPS also complies with international safety and quality standards, ensuring reliable performance and peace of mind.

It holds certifications such as CE, EAC, and RCM, demonstrating adherence to industry regulations.

Additionally, the unit features a maximum short-circuit current of 10 kA,

further enhancing its safety and resilience in high-demand environments.

Warranty and Support Services of Schneider E3SUPS15KHB1 On-Line UPS:

Schneider Electric provides a two-year on-site repair or replacement warranty for the E3SUPS15KHB1 UPS, that is including factory-authorized startup services.

This warranty ensures that businesses receive prompt support and service in case of any operational issues, whereas enhancing reliability and longevity.

A Reliable Power Backup Solution:

The Schneider E3SUPS15KHB1 On-Line UPS is an ideal solution for businesses seeking a robust and efficient power backup system.

Besides its high-performance specifications, easy installation, and expandable battery capacity, this UPS guarantees uninterrupted power supply for critical applications.

Whether for data centers, electrical rooms, or industrial setups, the Schneider Easy UPS 3S series provides a cost-effective and reliable power protection solution.

Schneider On-Line UPS
