Schneider E3LUPS500KHS On-Line UPS, 500kVA/500kW, 3 Ph, 3L, 400V, 3:3 UPS, Startup 5×8, Tower

Schneider E3LUPS500KHS On-Line UPS

500kVA/500kW, 3 Ph, 3L, 400V, 3:3 UPS, Startup 5×8, Tower

High-Performance 500kVA On-line UPS for Critical Power Protection:

Schneider E3LUPS500KHS Easy On-Line UPS 3L is a robust, high-capacity 3-phase uninterruptible power supply system designed to deliver 500 kVA/500 kW of reliable, clean power.

Engineered for mission-critical environments such as data centers, industrial facilities, and commercial buildings,

this UPS also supports business continuity by providing consistent power during outages and electrical disturbances.

It operates on a double conversion online topology, that is ensuring maximum protection for sensitive equipment by isolating it from power fluctuations and outages.

Schneider E3LUPS500KHS

Efficient and Flexible Input/Output Capabilities of Schneider E3LUPS500KHS On-Line UPS:

This Easy UPS 3L model is compatible with 400V, 380V, and 415V input and output voltages, that is offering maximum versatility for global installations.

Besides a wide input voltage range of 323V to 477V and a strong power factor of 0.99 at full load, it ensures stable operation and optimal performance.

It supports a maximum input current of 899 A and can withstand short-circuit currents up to 35 kA.

The unit also features low input harmonic distortion (<3%), helping improve energy efficiency and reduce operational costs.

Reliable Battery System with External Battery Support:

The E3LUPS500KHS uninterruptible power supply supports an external battery system, that is allowing flexible runtime options tailored to business needs.

The battery voltage ranges from +/- 216V to +/- 300V, with discharge voltage limits between +/- 172.8V to +/- 240V.

Smart battery management and test modes help ensure optimal battery performance and longevity.

The UPS also includes a 5×8 start-up service, ensuring professional installation and configuration for peak performance.

Schneider On-Line UPS

Compact Design with Advanced User Interface of Schneider E3LUPS500KHS On-Line UPS:

Despite its powerful capabilities, the Schneider UPS 3 Phase is compact, measuring 197 cm in height, 100 cm in width, and 85 cm in depth, with a net weight of 640 kg.

The intuitive touchscreen LCD display provides an easy-to-navigate interface for monitoring system performance and configuring settings.

The system is also USB compatible, enabling quick data access and updates.

Its white RAL 9003 finish blends seamlessly into modern facility environments.

EcoStruxure Ready and Environmentally Resilient:

This UPS is EcoStruxure Ready, enabling remote monitoring and integration into Schneider Electric’s smart infrastructure solutions.

It operates efficiently in ambient temperatures from 0 to 30°C and at altitudes up to 4921 ft.

Besides an IP20 protection rating and 72 dB acoustic level, it balances durability with workplace comfort.

Backed by a 2-year on-site warranty, the E3LUPS500KHS ensures long-term performance and peace of mind.
