Schneider RM35JA32MW Relay: Enhancing Electrical System Efficiency
Product Overview Schneider RM35JA32MW Relay
The Schneider RM35JA32MW is a current control relay from the RM35-J series, designed to monitor and manage current levels in electrical systems. It ensures protection and automation by detecting abnormal current conditions, making it ideal for use in industrial and commercial applications.
Key Features
-
Product Type: Current control relay
-
Model: RM35JA32MW
-
Series: RM35-J
-
Monitoring Range: 0.15 to 1.5 A AC
-
Control Circuit Voltage: 24 to 240 V AC/DC
-
Output: 2 changeover contacts (2 C/O – SPDT)
-
Mounting: DIN rail
-
Response Time: Adjustable delay on trip/reset
-
Hysteresis: Adjustable
-
LED Indicators: For relay status and supply voltage
-
IP Rating: IP20 (terminals), IP30 (housing)
Functions
-
Overcurrent Monitoring
Trips when current exceeds the preset upper threshold. -
Undercurrent Monitoring
Trips when current falls below the preset lower threshold. -
Window Mode
Trips when current goes outside a specified current band. -
Adjustable Hysteresis
Prevents frequent switching by creating a buffer range.
Applications
-
Industrial machinery current monitoring
-
Motor protection and overload detection
-
Electrical panels and distribution systems
-
HVAC systems
-
Pumps, compressors, and conveyor belts
Benefits
-
Improves system reliability and protection
-
Prevents equipment damage from overcurrent or undercurrent
-
Easy setup with adjustable dials
-
Compact design suitable for control panels
-
Universal compatibility with wide control voltage range
